Name: Pictometry 2020 Orthophoto Tiles

Display Field: ImageName

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: Pictometry uses a grid of approximately half-mile square areas called "cells" that define a project area. Pictometry sometimes still refers to these as "sectors", even though the cell size changed for 2020. This pt20so39 layer was made by appending the two original Pictometry 3-inch and 9-inch individual photo areas described below to make one layer. A new RESOLUTION field with '3-inch' or '9-inch' was added. pt20sor3 displays individual 3-inch orthophoto tiles areas where each ortho tile covers a square area consisting of a full "cell". pt20sor9 displays individual 9-inch orthophoto tiles areas where each ortho tile covers a square area consisting of one full "cell". The tiles defined by this layer represent the areas covered by each of the 3-inch and 9-inch resolution orthophotos in JPG format in the Pictometry 2020 data "AZPIMA20-TILES-3INCH" and "AZPIMA20-TILES-9INCH" directories. Known Errors/Qualifications: While these Pictometry cells are approximately 1/2 mile square, they are not based on PLSS sections and are offset considerably from the PLSS section grid. Lineage: This pt20so39 layer was made by appending the two original Pictometry pt20sor3 and pt20sor9 layers individual photo areas to make one layer. A new RESOLUTION field with '3-inch' or '9-inch' was added. Spatial Domain: Eastern Pima County Rectified: n/a Maintenance Organization: Pima County ITD GIS Library Input: Shape Std Primary Source Organization: Pictometry International Corp. Primary Source Date: 20200922 Primary Source Format: Shape Secondary Source Organization: Pima County ITD GIS Secondary Source Contact: John Dickinson Secondary Source Date: 20200929 GIS Contact: John Dickinson

Copyright Text: Pima County Information Technology Department - Geographic Information Systems\n33 N Stone Ave., 15th Floor\nTucson, AZ 85701

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 394944.0
YMin: 202488.0
XMax: 1179024.0
YMax: 564168.0
Spatial Reference: 2868  (2868)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [252, 234, 201, 255]
Outline:
Style: esriSLSSolid
Color: [110, 110, 110, 255]
Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• ImageName ( type: esriFieldTypeString, alias: ImageName, length: 44 )
• ImagePath ( type: esriFieldTypeString, alias: ImagePath, length: 254 )
• ImageExt ( type: esriFieldTypeString, alias: ImageExt, length: 3 )
• ShotLevel ( type: esriFieldTypeString, alias: ShotLevel, length: 1 )
• ShotType ( type: esriFieldTypeString, alias: ShotType, length: 2 )
• ShotOrient ( type: esriFieldTypeString, alias: ShotOrient, length: 2 )
• ShotDate ( type: esriFieldTypeString, alias: ShotDate, length: 20 )
• GSD ( type: esriFieldTypeDouble, alias: GSD )
• ImageRows ( type: esriFieldTypeInteger, alias: ImageRows )
• ImageCols ( type: esriFieldTypeInteger, alias: ImageCols )
• ULx ( type: esriFieldTypeDouble, alias: ULx )
• ULy ( type: esriFieldTypeDouble, alias: ULy )
• URx ( type: esriFieldTypeDouble, alias: URx )
• URy ( type: esriFieldTypeDouble, alias: URy )
• LRx ( type: esriFieldTypeDouble, alias: LRx )
• LRy ( type: esriFieldTypeDouble, alias: LRy )
• LLx ( type: esriFieldTypeDouble, alias: LLx )
• LLy ( type: esriFieldTypeDouble, alias: LLy )
• Resolution ( type: esriFieldTypeString, alias: Resolution, length: 8 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STArea() ( type: esriFieldTypeDouble, alias: Shape.STArea() )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
